ULTRASONIC AMR WATER METER – Telangana
We are a leading manufacturer of Ultrasonic AMR (Automatic Meter Reading) Water Meters in Telangana, offering advanced and intelligent water metering solutions designed for accuracy, reliability, and long-term performance. Utilizing cutting-edge ultrasonic transit-time technology, our meters are completely non-mechanical and maintenance-free, making them ideal for domestic, commercial, and municipal water supply systems across the state.
Our ultrasonic AMR meters are available in valve-integrated and non-valve configurations, providing features such as remote shutoff, real-time monitoring, and smart IoT-based water management. They support automated billing systems and ensure accurate readings even under challenging water conditions involving sand, rust, or air bubbles. With no moving parts, these meters deliver extended lifespan, stable performance, and consistent accuracy.
Built to comply with MID and ISO standards, our Ultrasonic AMR Water Meters offer secure wireless data communication, seamless integration with AMR/AMI networks, and low-pressure loss for optimal efficiency. Whether used in residential apartments, industrial facilities, commercial buildings, or municipal water supply systems, these meters ensure precise measurement, lower maintenance costs, and sustainable water resource management.
Trusted across Hyderabad, Warangal, Karimnagar, Khammam, Nizamabad, Mahbubnagar, and Nalgonda, our smart ultrasonic water meters are widely recognized for their energy efficiency, accurate performance, and reliable operation. Choose our Ultrasonic AMR Water Meters in Telangana for advanced technology, durable quality, and cost-effective water metering solutions.
Technical Specification:
- Measurement Principle: Ultrasonic transit-time flow measurement
- Meter Type: Non-mechanical, maintenance-free
- Accuracy Class: Class 2 (±2%) as per ISO 4064 / OIML R49
- Nominal Diameter (DN): 15 mm to 300 mm (custom sizes available)
- Flow Range: 0.01 m³/h to 1,200 m³/h (depending on model)
- Working Pressure: Up to 16 bar (PN16)
-
Temperature Range:
-
Cold water: 0.1°C to 50°C
-
Hot water (optional): up to 90°C
-
-
Power Supply:
-
Built-in lithium battery (10–15 years lifespan)
-
External power option for AMI systems
-
-
Communication Interface:
-
RS485 / Modbus
-
Wireless LoRa / NB-IoT / GPRS / RF / Bluetooth (optional)
-
-
Display:
-
Digital LCD display with multi-parameter readout
-
Units: m³, L, flow rate, error code, signal strength
-
-
Material of Construction:
-
Body: Brass / Composite / Stainless Steel
-
Sensor: Ultrasonic type with corrosion-resistant coating
-
-
Pressure Loss: ≤ 0.025 MPa
-
Compliance Standards: ISO 4064 / OIML R49 / MID / BIS Certified
Key Benefits:
- High Accuracy: Ensures precise measurement of water consumption, even at very low and high flow rates, maintaining consistent accuracy throughout its lifespan.
- Non-Mechanical Design: No moving parts—eliminates wear and tear, minimizes maintenance, and guarantees long-term reliability.
- Maintenance-Free Operation: Resistant to sand, rust, air bubbles, and impurities—ideal for varying water conditions in Tamil Nadu’s urban and rural areas.
- Smart Data Monitoring: Enables real-time data transmission through AMR/AMI systems using wireless communication such as LoRa, NB-IoT, or GPRS.
- Remote Meter Reading & Control: Allows utility operators to collect data remotely, reducing manpower and manual reading errors while supporting remote valve shut-off.
- Energy Efficient: Equipped with a long-life lithium battery offering up to 15 years of continuous operation without replacement.
- IoT-Enabled Connectivity: Seamlessly integrates with smart city infrastructure and digital water management platforms for efficient billing and leakage detection.
- Tamper & Reverse Flow Detection: Built-in alerts for tampering, reverse flow, and abnormal usage to ensure secure and transparent operations.
- Durable & Weatherproof: IP68-rated body ensures full protection against dust and water ingress, suitable for outdoor and underground installations.
- Compliance & Quality Assurance: Certified to international standards like ISO 4064, OIML R49, and MID, guaranteeing performance, reliability, and safety.
Features
- Bidirectional flow measurement
- Line size 15/20/25/32/40mm
- Battery life 10years
- Compatible with automatic reading system
- Manufactured as per IS standard
- Better accuracy
- Indication: Reverse flow, Battery flow, Empty pipe
- Valve control
- Remote reading wired/Wireless (RF Based)
- Material of construction brass
Why Choose Us?
- Leading manufacturer of ultrasonic water meters in India
- Best price guarantee without compromising on quality
- Made in India – engineered for Indian water conditions
- Advanced ultrasonic technology for high accuracy and zero maintenance
- IP68-rated for reliable use in outdoor and submerged environments
- Custom solutions tailored for domestic, commercial, and municipal use
-
Fast delivery and reliable after-sales support across India
Product Details:
| Application Media | Water |
| Model Name/Number | RLT-AMR-ULTRA |
| Brand | RLT Solutions |
| Flow Range | As per model |
| Enclosure Rating | IP68 |
| Temperature Range | 0°C to 55°C |
| Pressure Rating | Up to 1.6 MPa |
| Country of Origin | Country of Origin |
